Reference: RF35322
Brand: RONSTAN
30mm - Triple/ Cleat Series 30
Sheave 30mm Max. rope 8mm M.W.L. 550kg
Banner
Ball Bearing Orbit Blocks™ have been engineered to achieve the highest possible strength-to-weight ratio, using composite reinforced polymer materials and a Dyneema® link attachment instead of metal components.
The unique orbital version of our 2-stage ball bearing system maximises the available bearing surface and positions recirculating ball bearings exclusively within the loaded area of the sheave. A secondary full-contact bearing maintains low friction across the full working load range.
The Dyneema® link, realised in high-grade SK78 fibre, is easily fitted and retained securely by a moulded retainer clip. The flexible link allows limited articulation in a 0° or 90° orientation, while swivel head models with stainless steel shackles provide full rotation and ultimate durability.
Orbit Blocks™ are fitted with our carbon-fibre reinforced C-Cleat™ for secure rope holding with low entry and exit efforts, and fairleads for fast action from any angle. Cleat arms have a wide range of adjustment and calibration marks for setting your preferred cleating angle.
Multiple gripping faces machined into our ratchet block sheaves work in conjunction with our unique cross-hole geometry, delivering up to 20:1 holding power to resist slipping of the loaded line while minimising rope wear. Ball bearings ensure minimum friction under load and a free running sheave when the ratchet is disengaged.
Control switches are located on both sides of the block to remain accessible wherever the block is fitted. In auto mode, the ratchet mechanism engages when load is applied but disengages when released to let the sheet run out freely – ideal for gybing asymmetric spinnakers. In manual mode, the switch is used to set up the block with ratchet either on or off as required.
Reference: RF35322
Brand: RONSTAN
Sheave 30mm Max. rope 8mm M.W.L. 550kg
Reference: RF35312
Brand: RONSTAN
Sheave 30mm Max. rope 8mm M.W.L. 550kg
Reference: RF35101
Brand: RONSTAN
Sheave 30mm Max. rope 8mm M.W.L. 300kg
Reference: RF35100D
Brand: RONSTAN
Sheave 30mm Nylatron Max. rope 8mm M.W.L. 300kg
Reference: RF35212
Brand: RONSTAN
Sheave 30mm Max. rope 8mm M.W.L. 450kg
Reference: RF45101
Brand: RONSTAN
Sheave 40mm Max. rope 9mm M.W.L. 325kg
Reference: RF45111
Brand: RONSTAN
Sheave 40mm Max. rope 9mm M.W.L. 325kg
Reference: RF35101D
Brand: RONSTAN
Sheave 30mm Nylatron Max. rope 8mm M.W.L. 300kg
Reference: RF45110
Brand: RONSTAN
Sheave 40mm Max. rope 9mm M.W.L. 325kg
Reference: RF25109
Brand: RONSTAN
Sheave 20mm M.W.L. 250kg Includes 750 mm (30") x 1.7mm (1/16") diam lashing cord
Reference: RF35141
Brand: RONSTAN
Sheave 30mm Max. rope 8mm M.W.L. 250kg
Reference: RF35100A
Brand: RONSTAN
Sheave 30mm Max. rope 8mm M.W.L. 300kg
